Upgrade ZEISS SteREO Discovery.V12 to LED Fluorescence

The ZEISS SteREO Discovery.V12 is a high-performance stereo microscope designed for life science research, developmental biology, and precision sample observation. Researchers often require fluorescence capability to visualize labeled specimens while preserving the advantages of stereomicroscopy.

The MSHOT MZX-LED Stereo Fluorescence Module provides an efficient fluorescence upgrade solution for the Discovery.V12, enabling fluorescence observation without replacing the existing microscope system. Stable LED illumination and flexible excitation options support demanding biological and research applications.

Share:

Get Exclusive Offers and Updates!

    Description

    ● Designed for ZEISS SteREO Discovery.V12 fluorescence upgrade

    ● Optimized for advanced stereo fluorescence observation

    ● Stable and uniform LED illumination

    ● Flexible excitation wavelength options

    ● Mercury-free LED technology

    ● Ideal for biological research and developmental studies

    Feature

    MZX-LED Fluorescence Module Features

    ■ Compact design contains light source and filters in one unit.
    ■ Instant on-off, no need waiting of pre-heating or cooling.
    ■ Unique dual light path design, higher and more uniform brightness.
    ■ Two-color three-channel structure design, standard configuration of two large-view fluorescence channels and one bright field channel for external bright field lighting to pass.
    ■ Digital screen shows light intensity 0~100% of each channel.
    ■ Memory function of last fluorescence lighting intensity individually.
    ■ No requirement of external or added power supply.
    ■ Linked rotating knob move filter cubes and light source by one step
    ■ CE, FCC, EMC, EU, ISO certified.

    MZX-LED Fluorescence Module classic applications

    Biological live imaging, Nematode, Chick CAM, Drosophila, Zebrafish, Embryo, Forensic investigation.

    Specifications

    Item Specifications
    Filter Cube: B FB-B-M : EX: 470/40nm; DM: 505nm; EM: 530/40nm;
    FL-B-M : EX: 460-490nm; DM: 500nm; EM: 520nm LP;
    Filter Cube: G FB-G-M : EX: 530/40nm; DM: 565nm; EM: 605/55nm;
    FL-G-M : EX: 510-550nm; DM: 570nm; EM: 590nm LP;
    Filter Cube: U FB-U-M : EX: 375/28nm; DM: 415nm; EM: 460/50nm;
    FL-G-M : EX: 330-380nm; DM: 400nm; EM: 420nm LP;
    Filter Cube: Y FL-Y-M : EX: 540-580nm; DM: 600nm; EM: 610 nm LP
    Excitation Light Source 3W LED light source (5W for Y/G), adjustable brightness, visual digital display
    Observation Method Fluorescence / Brightfield switching
    Power Input  DC 12V 2A
